1550CH Skin Resurfacing & Tightening/ Wrinkle, Acne Scar & Pigment Lesions Removal Machine
Treatment Theory
1. Loss of collagen makes skin darken and aging.
2. 1550nm Er.bium Glass Fractional Laser work on the skin with fractional location.
3. Laser beam forms a dense three dimensional physical heated zone within the treatment tissue.
4. Automatic recovery of heated areas and heat conduction effect lead to the regeneration of collagen and skin vitality.
Multiple focal spot rectangle patterns
Multiple scanning graphics, whic can be selected according to the treatment part and the tissue area.
—
Choosing accurate energy and position locating for differnet treatment tissue so as to realize skin resurfacing.
Applications
1. Skin aging sagging and inelastic.
2. Eye wrinkles, forehead wrinkles, striated lines, fine wrinkles.
3. Acne acne scars.
4. Large pores, oily skin.
5. Stretch marks.
Features & Advantages
1.Comfortable
Rapid and uniform distribution of the beam.
2.Fast
Preset scanning form, covering an area of 3.0cm*3.0cm each time.
3.Low cost
Low cost for maintenance for no disposable parts.
4.Flexible
With flexible operation, penetration depth is controllable.
Model name : 1550CH
| Laser type | Germany Laser |
| Laser wavelength |
1550nm |
| Pulse energy | 10mj-200mj(step 2mj) |
| Pulse interval | 1ms-100ms(step 1ms) |
| Pulse width | 0.067ms-0.67ms |
| Laser power | 30w |
| Output Graphics | Trangle / square / rectangle / rhombus / upgradeable / DIY graphics |
| Output mode | CPG |
| Beam delivery System | Fiber |
| Spot size | 50um-200um continuously adjustable |
| Spot density(/CM²) | 6*6，12*12，18*18，24*24 |
| Scanning mode | Sequential / Randomized |
| Scanning area | 1*1cm²，2*2cm²，3*3cm² |
| Cooling mode | wind |
| Dimensions | 52cm*79cm*143cm |
| Gross weight | 50kgs |
| Power Supply | AC110/220V±10%, 50-60HZ |
